Physical Characeristics |
|
Item |
Unit |
3 mm |
4 mm |
6 mm |
Remark |
|
Specific Weight |
|
1.52 |
1.38 |
1.23 |
|
|
Weight |
Kg/m2 |
4.57 |
5.5 |
7.36 |
|
|
Heat expansion |
*10 -6/℃(-20 ℃ -60℃) |
24 |
24 |
24 |
ASTM D696 |
|
Heat conduction rate
(apparent) |
Kcal/.h. ℃ /kcal |
0.43 |
0.39 |
0.35 |
ASTM C976 |
|
Thermal endurance
(apparent) |
m2 .h. ℃ /kcal |
0.19 |
0.19 |
0.2 |
ASTM C976 |
|
Heat distortion temperature |
℃ |
116 |
115 |
115 |
ASTM D648 |
|
Mechanical Characeristics |
|
Item |
Unit |
3 mm |
4 mm |
6 mm |
Remark |
|
Tensile Strength |
Kg/m2 |
6.2 |
4.9 |
3.5 |
ASTM E-8 |
|
Bending strength |
Kg/m2 |
5.9 |
4.5 |
3.1 |
ASTM E-8 |
|
Prolongation |
% |
12 |
14 |
17 |
ASTM E-8 |
|
Impact Shear resistance maximum load |
*10(5)kg.mm2 |
7.3 |
14 |
35.4 |
ASTM C393
(20cm span) |
|
Bending elastic modulus |
kg |
1380 |
1650 |
2100 |
ASTM D-732
(￠ 50mm) |
|
Shear Strength |
Kg/mm2 |
2.9 |
2.6 |
2.2 |
ASTM D-732
(￠ 50mm) |
|
Dupont Impact Test -Depth of Deformation (mm) |
|
Steel ball weight( kg ) |
Height( mm ) |
3mm |
4mm |
5mm |
|
0.3 |
300 |
0.74 |
0.56 |
0.38 |
|
0.3 |
500 |
1.17 |
0.81 |
0.5 |
|
0.5 |
300 |
1.18 |
0.88 |
0.51 |
|
0.5 |
500 |
1.64 |
1.36 |
0.79 |
|
1 |
300 |
1.97 |
1.71 |
0.96 |
|
1 |
500 |
2.6 |
2.29 |
1.52 |
Specifications
Thickness: 4 mm standard, special use: 3 mm, 6 mm
Width: 1220mm standard, special use: 1250mm, 1500mm.
Length: 2440mm standard, special use: 3200mm, 6000mm, max. 8000mm
Aluminum coil thickness: 0.50 mm standard, special use: 0.45mm, 0.40mm, 0.35mm, 0.30mm
Standard Core material types: Normal quality core material, high quality non-breakable core material
Fire resistant core material B1 and A2 degree.(B1- nonflammable, A2-incombustible)
Certification: ISO 9001, SGS, TUV (for A2 fireproof core )
Delivery Time: Within 15~20 days after receiving down payment
Payment Term:
30% T/T in advance, 70% payable before delivery or L/C at sight
Pacakge: High standard Exporting Package, wooden pallets,
Plywood surrounding four sides and the top with strap tightened
Production Capacity: 15000 SQM PER MONTH
Factory Location:
Jiyan RD, Huaiyin District, Jinan city, Shandong PR, CHINA P/O: 250021
