Signage grade aluminum composite panel

The product is the first aluminum composite material with a lacquer system optimization.

The substrate can be directly used for digital printing, digital soar surface enhanced UV and solvent ink adhesion.

UV board dedicated to digital printing with the ACP, with a smooth surface and glossy, superior print clarity, and salient characteristics

of ink absorption capacity. Aluminum composite panels as dedicated high-end digital printing are new dynamic advertising material.

Product Specifications:

Thickness: 2mm~6mm, recommended 2mm, 3mm

Width: 1000~2000 mm, recommended: 1220mm, 1250mm, 1500mm, 2000mm

Panel length: up to 5800 mm, recommended: 2440mm, 3050mm, 4050mm

Aluminum thickness: 0.10mm~0.5mm, recommended: 0.2mm, 0.3mm

Raw Materials:

Basic Aluminum: high-strength aluminum alloy

Plastic core: non-toxic low density polyethylene

Surface coating: PVDF, PE

Special Excellence:

-Smooth surface, rich texture, various color: RAL and Pantone colors are provided, including high gloss, matt gloss, brushed, mirror,

wooden finished board and customerized to your needs.

-Various designs and length: Width is from 1000mm to 2000mm.

Length can be customized to your requirements beyond the standard size according to the processing techniques.

-Simple processing, various modalities ACM can be processed to various forms and undergone various processes

such as cutting, bending, punching, sticking and painting.

-Lowest rate of expand and shrink: Dimensions stable, will not expand or shrink under adverse circumstances,

with wide temperature resistance(-50 ~ 80 celsius degree)

-High adhesive intensity The American Dupont technology insures the board not distort, or strip away cockle,

shelling during the cutting and bending.

-Environment friendly It is a green building material, no radiation or other polution

-Superior weather-resistance and rub-resistance Surface treatment with high grade ultraviolet-resistant polyester paint (ECCA) request,

guarantee 8-10 years; if use KYNar 500 PVDF paint, guarantee 15~20 years.

-Superior Rigidity Unbelievable light with amazing hardness
