Model	LQ500	LQ500R
Laser tube	Water cooling Co2 sealed glass
Control system	32 Bit DSP with Flash memory
Drive type	Stepper motor
Laser Power	50W	50W
Working Size (mm)	300 x 500	300 x 500
Adjust Table (mm)	200	200
Max speed	800 mm/s
Image form	Plt, Dxf, Bmp, Ai, Dst
Resolution	1000 DPI
Repeatability	0.01 mm
Interface	USB 2.0
Power	110~240V/ 50~60Hz
Warranty	12 Months
Machine dimensions (mm)	1150*670*890	1150*670*890
Package dimensions (mm)	1270*790*1050	1270*790*1050
G. W. (Kg)	125	125
