Off Gird Household Solar System--260W

LQ-HS-90 AC System  $ 260/SET
Technical data:
System	Peak power of solar panel		90W
	System voltage		12VDC
	Best output/day		405WH
Inverter	Output wave		Pure sine wave
	Output voltage		AC110V/220V
	Output frequency		50HZ/60HZ
	Pm		200W
Solar panel	Pmax		45W*2
	Vmp		17.5V
	Imp		2.6A* 2
Charger	Charger voltage & current		12V10A
Battery	Capacity		12V100AH
Package data:
Package	Size (L*W*H  mm)	Weight (kg)	20' (pcs)	40' (pcs)
Power box	320*200*220	14.65	413	826
Solar panel	630*551*80	13
Battery	241*150*258	16
Load reference:
Name of Load	Power(W)	Quantity	Working Time per Day (H)	Working Days
Color TV	65	1	2	3 days
lamp	11	2	3
