| EPHC-EC |
| SOLAR CONTROLLER FOR SOLAR HOME SYSTEMS |
| EPHC series is a reliable and economical solar controller. |
| It is ideal for small solar home system or rural electrification PV system. |
| Features |
| Microcontroller digital accuracy |
| PWM Charge mode |
| State of charge (SOC) |
| Temperature compensation |
| Automatic detection of the voltage |
| Electronic protection |
| Short circuit protection |
| Reverse polarity protection |
| Reverse current protection at night |
| Over charging or discharging protection |
| Over load protection |
| Display |
| 3 LED indicators |
| PV: Green -charging |
| Battery: Green-Yellow-Red |
| Load: Red -low voltage warning and disconnect |
| LED blinking shows mistakes |
| Technical specification |
| EPHC10-EC series: 12 VOLT or 12/24 VOLT auto work, 10 AMPS (for PV and load) |
| Equalization voltage: |
14.8 Volt |
| Boost voltage: |
14.4 Volt |
| Float voltage: |
13.6 Volt |
| Low voltage disconnect(LVD) |
11.10 Volt |
| Low voltages reconnect (LVR): |
13.1Volt |
| Temperature compensation: |
-30mv/¡æ/12V |
| Self-consumption: |
6mA maximum |
| Terminals: |
for wire sizes to 2.5mm2 |
| Temperature: |
-35¡æ to +55¡æ |
| Notes: It is for 12V system. Please X2 for 24V system. |
| WARRANTY: One year warranty period. |
