| On Grid Household Solar System-2000 W |
| Items |
Technical Parameter |
Quantiy |
Total |
solar panel:
200W
Size:(mm)
1580*808*40 |
Max output power of solarsystem |
2KW |
10 PCS |
$3,640.00 |
| Max power voltage of solar system |
260V |
| Max power current of solar system |
7.69A |
| Open circuit voltage of solar system |
315V |
| Short circuit current of solar system |
8.63A |
On grid
Solar inverter |
Rated Power(KW) |
2KW |
2 KW
1 SET |
$1,063 |
| Allow the max PV square power |
2.2KW |
| Max open voltage |
440v |
| MPPT range(VDC) |
200～400@306 |
| Rated AC output power |
2KW |
| Grid voltage range(VAC) |
180～260/90～130 |
| Rated Grid frequency |
50Hz/60Hz |
| Power Factor |
﹥0.99% |
| Max. Efficiency |
94% |
| Euro Efficiency |
93.50% |
| THD(Iac) |
﹤4% |
| MPPT precision |
99% |
| Electromagnetic Compatibility |
EN50081/EN50082 |
| Power Detection |
DIN VDE 126 |
| Equipment |
0W |
| Waterproof and Dustproof Class |
IP20(indoor)/IP65 |
| Prevent island method |
Vac ; Fac |
| Cooling method |
Wind cooling |
| Ambient temperature of using |
-20℃~+50℃ |
Mounting
Frames |
Flat roof |
|
$599.00 |
| Tilt roof (small tiles) |
|
$450.00 |
| IEC/TUV/ISO/CE; 10 years 90% power, 25 years 85% power, 5 years warranty for solar module |
