2KW Off Grid Solar Home System

2KW off grid  Household Solar PV System--------Model: LQ-HS-2KW -AC
System Configuration
Series No.	Items	Specification	Quantity	Weight
1	Solar Panel 2000Wp	125 W poly solar panel	16 PCS	180 KG
2	Power Box	Controller 24V/ 40A	2 PCS	35 KG
		Pure sine wave inverter24V/4000W	1 PCS
		Controller cabinet	1 PCS
3	Lead Acid Battery	Capacity 24V/1000Ah, not included in quotation and package
4	Accessories	Mounting brackets, cables 60m	1 SET	140 KG
Reference for Use(System Capacity: 3620VA)
Name of Load	Power(W)	Quantity	Working Time per Day (H)	Working Days
Color TV	65W	2	2	3 rainy days
Satellite TV Receivers	25W	1	3
LCD Computer	100W	2	3
Energy-saving lamp	11W	6	3
Printer	30W	1	2
Electrograph	150W	1	2
Water Pump	200W	1	3
Refrigeratory	100W	1	6
Washing machine	300W	1	3
This system can provide electricity for home 6 hours per day. Peak output power of solar panel is 2000Wp. Capacity of battery: 24V/1000Ah System DC voltage: 24V; Output AC: 110V/220V Maximum power of loads: 3000Wp
