6KW off grid  Household Solar PV System--------Model: LQ-HS-6KW -AC
System Configuration
Series No.	Items	Specification	Quantity	G.W.
1	Solar Panel 6000Wp	125 W poly solar panel	48 PCS	528 KG
2	Power Box	Controller 48V/ 60A	2  PCS	70KG
		Pure sine wave inverter48V/6000W	3  PCS
		Controller cabinet	1 PCS
3	Lead Acid Battery	12V/150Ah	32 PCS	1344 KG
4	Accessories	Mounting brackets, cables 60m	1 SET	420KG
Reference for Use(System Capacity: 9000VA)
Name of Load	Power(W)	Quantity	Working Time per Day (H)	Working Days
Color TV	65W	2	6	2 rainy days
Satellite TV Receivers	25W	2	6
LCD Computer	100W	1	6
Energy-saving lamp	11W	8	6
Printer	30W	2	2
Electrograph	150W	2	2
Water Pump	200W	1	2
Refrigeratory	100W	1	24
Washing machine	300W	1	2
Air-condition	1000W	1	7
This system can provide electricity for home 6 hours per day. Peak output power of solar panel is 6000Wp. Capacity of battery: 48V/1200Ah System DC voltage: 48V; Output AC: 110V/220V, 50/60HZ Maximum power of loads: 7000Wp;  Above loads can be powered simultaneously.

Batteries excluded: USD 13857.81/SET FOB QINGDAO

Batteries included: USD 20732.81/SET FOB QINGDAO
