Product Name	40W portable AC solar power system
Model No.	JNMA-040A
Application	Being able to drive notebook computer / TV and other digital devices
	Best choice for user and herdsman in remote areas
	For outpost, Field work, design and manufacture of tourist camps
System Configuration	Polycrystalline solar panel 20W	2 PCS
	DC charger controller 10A	1 PCS
	Lead acid storage battery 12AH	4 PCS
	Power control box	1 PCS
	Solar Inverter(DC to AC) 500W	1 PCS
	5W/12V DC lamps	2 PCS
	Brackets and PV cable	1 SET
Technical parameters	Solar power	40Wp
	Operating voltage	18V
	Battery	12V/48Ah
	DC Lighting power	5W * 2
DC output control	Battery voltage falls below 10.8V, ouput suspend (red light on),
	higher than 12.6V (red light off).
	Battery voltage falls below 10.5V, output suspend (switch light OFF),
	Higher than 12.6V start work (switch light ON).
Working Hours	Battery fully charged, DC 5W*2 lights work 60 hours continuous.
Status indication	Green LED light ON	Power indicator
	Yellow LED light ON	Charging indicator
	Red LED light ON	Ouput cut-off
Dimension	700mm x 320mm x262mm
Pkg size	720mm x 350mm x280mm
Net Weight	28KG
Gross Weight	32KG
